The M500-384 USB Ultrasound Microphone enables you to make high-quality, full spectrum recordings of bat calls or other ultrasonic signals with a wide variety of computers/laptops/tablets/smartphones, using the sound recording software of your choice. The M500-384 uses standard sound device drivers and does not require installation of any custom drivers.
Like the M500, the M500-384 comes in a slim and durable aluminium enclosure and utilizes the same advanced electret microphone technology as the well-known D500X detector.
The M500-384 can be used both in directional and omni-directional modes. The M500-384 is the ideal choice if you intend to use your smartphone for ultrasound recording. Also consider this model if you need to be independent of a specific OS or software. The software you choose to use must support recording at 384 kHz. Works with Android, Linux (Ubuntu), OS X, iOS or Windows. Please verify the hardware compatibility of the software you choose and that it supports recording at 384 kHz. Certain tablets - particularly low-end devices - have been found not to support USB audio at 384 kHz.
A 0.5 m USB (type-A to mini-B) cable is included. A type mini-B to micro-B/OTG USB cable would also work but is not included. Suitable for use with a smartphone or tablet.
*Tablet non included. Does not connect/snap onto end of the phone/tablet*.
Specifications
Microphone: Advanced electret
Sampling frequency: 384 kHz
ADC resolution: 16 bits
Frequency range: 10 kHz - 160 kHz
Interface: USB 2.0, full speed, OTG/host
Anti-aliasing filter: 8th order, 160 kHz
Size: 43 x 114 x 13 mm (incl microphone horn)
Weight: 60 g
Power: USB bus powered
The following list includes some programs that can be used with the M500-384.
Windows
BatSound Touch, SoundChaser, Audacity
Android
Bat Recorder, USB Bat Detector
iOS
Ultrasonic Analyzer
Linux
Audacity
OS X
Audacity
